Product Description
规格MODEL | 外形尺寸DIMENSIONS(mm) | |||
D | d | L | A | |
CLQHB-1/8"-N | 12.00 | 3.20 | 25.60 | NPT1/8" |
CLQHB-1/4°-N | 16.90 | 6.40 | 37.40 | NPT1/4" |
CLQHB-3/8"-N | 24.70 | 935 | 45.20 | NPT3/8" |
CLQHB-3/8"X1/2"-N | 24.70 | 9.80 | 48.70 | NPT1/2" |
CLQHB-1/2"-N | 30.40 | 12.50 | 53.00 | NPT1/2" |
CLQHB-3/4°-N | 42.00 | 19.10 | 60.20 | NPT3/4" |
CLQHB-1"-N | 49.20 | 25.20 | 67.20 | NPT1" |
CLQHB-1/8"-R | 12.00 | 3.20 | 25.60 | R1/8" |
CLQHB-1/4°-R | 16.90 | 6.40 | 37.40 | R1/4" |
CLQHB-3/8°-R | 24.70 | 9.35 | 45.20 | R3/8" |
CLQHB-3/8"X1/2-R | 24.70 | 9.80 | 48.70 | R1/2" |
CLQHB-1/2°-R | 30.40 | 12.50 | 53.00 | R1/2" |
CLQHB-3/4°-R | 42.00 | 19.10 | 60.20 | R3/4" |
CLQHB-1"-R | 49.20 | 25.20 | 67.20 | R1" |
规 格 MODEL | 外形尺寸DIMENSIONS(mm) | |||
D | d | L | A | |
CLQHB-4x1/8"-N | 12.00 | 4.00 | 28.00 | NPT1/8" |
CLQHB-4X1/4"-N | 12.00 | 4.00 | 28.80 | NPT1/4" |
CLQHB-6x1/4"-N | 17.00 | 6.10 | 37.40 | NPT1/4" |
CLQHB-8x3/8"-N | 24.70 | 8.10 | 45.20 | NPT3/8" |
CLQHB-4x1/8"-R | 12.00 | 4.00 | 28.00 | R1/8" |
CLQHB-4X1/4°-R | 12.00 | 4.00 | 28.80 | R1/4" |
CLQHB-6x1/4°-R | 17.00 | 6.10 | 37.40 | R1/4" |
CLQHB-8x3/8"-R | 24.70 | 8.10 | 45.20 | R3/8" |
