PFA 90 Degree Elbow Sleeve-Insert Type

D

d

d2

D1

d1

d3

L

L1

CLQ1E-1/8"X1/8"

12.00

3.30

2.18

12.00

3.30

2.18

18.90

18.90

CLQ1E-1/4"X1/4°

15.72

6.45

3.95

15.72

6.45

3.95

28.80

28.80

CLQ1E-3/8"X1/4°

24.20

9.80

6.35

15.72

6.45

3.95

32.80

32.50

CLQ1E-3/8"X3/8"

24.20

9.80

6.35

24,20

9.80

6.35

37.10

37.10

CLQ1E-1/2"X1/4°

30.40

12.80

9.53

15.72

6.45

3.95

37.00

35.20

CLQ1E-1/2"X3/8°

30.40

12.80

9.53

24.20

9.80

6.35

40.60

39.40

CLQ1E-1/2"X1/2

30.40

12.80

9.53

30.40

12.80

9.53

44.20

44.20

CLQ1E-3/4"X1/2

42.00

19.20

15.80

30.40

12.80

9.53

55.50

49.20

CLQ1E-3/4"X3/4°

42.00

19.20

15.80

42.00

19.20

15.80

60.00

60.00

CLQ1E-3/4"X3/8"

42.00

19.20

15.80

24.20

9.80

6.35

52.50

44.40

CLQ1E-3/4"X1/4°

42.00

19.20

15.80

15.72

6.45

3.95

48.90

40.20

CLQ1E-1"xl/2"

49.20

25.70

22.20

30.40

12.80

9.53

63.10

54.40

CLQ1E-1"X3/4"

49.20

25.70

22.20

42.00

19.20

15.80

68.00

65.20

CLQ1E-1"XI"

49.20

25.70

22.20

49.20

25.70

22.20

70.50

70.50

CLQ1E-1-1/4"X1"

65.00

32.00

28.00

49.20

25.70

22.20

84.70

78.00

CLQ1E-1-1/4"X1-1/4"

65.00

32.00

28.00

65.00

32.00

28.00

91.20

91.20

CLQ1E-1-1/2"X1"

72.00

38.40

33.70

49.20

25.70

22.20

87.40

80.60

CLQ1E-1-1/2"X1-1/4"

72.00

38.40

33.70

65.00

32.00

28.00

94.90

94.70

CLQ1E-1-1/2"X1-1/2"

72.00

38.40

33.70

72.00

38.40

33.70

97.90

97.90

D

d

d2

D1

d1

d3

L

L1

CLQ1E-4X4

12.00

4.00

3.00

12.00

4.00

3.00

1900

19.00

CLQ1E-6X6

16.90

6.10

4.00

16.90

6.10

4.00

28.50

28.50

CLQ1E-8X8

24.70

8.10

6.00

24.70

8.10

6.00

35.90

35.90

CLQ1E-10X10

24.30

10.20

8.00

24.30

10.20

8.00

35.90

35.90

CLQ1E-12x6

30.40

12.00

10.00

16.90

6.10

4.00

35.10

35.40

CLQ1E-12x8

30.40

12.00

10.00

24.70

8.10

6.00

38.80

38.90

CLQ1E-12X12

30.40

12.00

10.00

30.40

12.00

10.00

41.70

41.70
