Product Description
规 格 MODEL | 外形尺寸DIMENSIONS(mm) | |||
D | L | L1 | d | |
CLQP-1/8" | 3.00 | 13.10 | 7.10 | 1.00 |
CLQP-1/4" | 6.25 | 23.50 | 14.00 | 2.00 |
CLQP-3/8" | 9.50 | 31.00 | 16.20 | 3.00 |
CLQP-1/2" | 12.50 | 36.00 | 19.00 | 3.00 |
CLQP-3/4" | 18.80 | 42.00 | 20.05 | 3.00 |
CLQP-1* | 25.20 | 45.70 | 22.70 | 3.00 |
CLQP-1-1/4 | 31.80 | 66.00 | 39.70 | 6.00 |
CLQP-1-1/2" | 38.10 | 72.40 | 42.40 | 6.00 |
