PFA Panel Mount Connector Sleeve-Insert Type

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Description


PFA Panel Mount Connector Sleeve-Insert Type Specifications


规 格 MODEL

外形尺寸DIMENSIONS(mm)

D

d

d2

D1

d1

d3

L

t

K

CLQ3P-1/8"

12.00

3.30

2.18

12.00

3.30

2.18

40.80

7.00

9.00

CLQ3P-1/4"

15.72

6.45

3.95

15.72

6.45

3.95

57.40

8.00

13.50

CLQ3P-1/4"X1/8"

15.72

6.45

3.95

12.00

3.30

2.18

48.80

7.00

9.00

CLQ3P-1/4"X3/8"

15.72

6.45

3.95

24.20

9.80

6.35

63.70

7.00

13.50

CLQ3P-3/8

24.20

9.45

635

24.20

9.45

6.35

70.20

8.00

20.50

CLQ3P-1/2"

30.40

12.80

9.53

30.40

12.80

9.53

79.40

8.00

24.50

CLQ3P-1/2"X3/4"

30.40

12.80

9.53

42.00

19.20

15.80

91.50

9.50

34.00

CLQ3P-3/4"x1"

42.00

19.20

15.80

49.20

25.70

22.20

112.10

9.00

34.00

CLQ3P-3/4"

42.00

19.20

15.80

42.00

19.20

15.80

10600

10.00

43.00

CLQ3P-1"

49.20

25.70

22.20

49.20

25.70

22.20

11600

10.00

44.00
