Product Description
规 格 MODEL | 外形尺寸DIMENSIONS(mm) | |||
D | d | d1 | L | |
CLQ1CP-1/4° | 16.90 | 6.45 | 3.95 | 25.30 |
CLQ1CP-3/8" | 24.70 | 9.80 | 6.35 | 40.00 |
CLQ1CP-1/2° | 30.40 | 12.80 | 9.53 | 35.80 |
CLQ1CP-3/4° | 42.00 | 19.10 | 15.80 | 43.10 |
CLQ1CP-1" | 49.20 | 25.70 | 22.20 | 47.20 |
CLQICP-1-1/4" | 65.00 | 32.00 | 28.00 | 68.70 |
CLQICP-1-1/2" | 72.00 | 38.00 | 33.70 | 73.20 |
