PFA Spigot Tee Sleeve-Insert Type

Type

D

d

d3

D1

D2

d1

d4

L

L1

L2

L3

L4

E

E1

CLQ1TT-1/4°xT1/4"xT1/4"

C

15.72

6.45

3.95

6.35

6.35

N/A

N/A

56.60

27.50

19.60

19.60

27.30

1.20

1.20

CLQITT-1/4°xT1/4"x1/4"

A

15.72

6.45

3.95

6.35

15.72

6.45

3.95

57.50

28.00

20.20

28.75

N/A

1.20

N/A

CLQ1TT-1/4"x1/4"xT1/4"

B

15.72

6.45

3.95

15.72

6.35

6.45

3.95

56.20

28.80

19.20

27.40

N/A

1.20

N/A

CLQ1TT-T3/8"x3/8"×T3/8"

D

24.20

9.80

6.35

9.53

9.53

N/A

N/A

74.20

36.40

2410

24.10

N/A

1.60

1.60

CLQ1TT-T3/8"x3/8"x1/4"

B

15.72

6.45

3.95

24.20

9.45

9.80

6.35

68.90

37.10

23.40

36.30

N/A

1.60

N/A

CLQITT-3/8'xT3/8"XT3/8"

C

24.20

9.80

6.35

9.53

9.53

N/A

N/A

73.50

37.10

24.10

24.10

37.10

1.60

1.60

CLQ1TT-3/8"×T3/8"×3/8"

A

24.20

9.80

6.35

9.53

24.20

9.80

6.35

74.20

37.10

24.10

37.10

N/A

1.60

N/A

CLQ1TT-3/8"×3/8"×T3/8"

B

24.20

9.80

6.35

24.20

9.53

9.80

6.35

74.10

37.10

24.10

43.50

N/A

1.60

N/A

CLQITT-3/8"x1/2"xT1/2"

B

24.20

9.80

6.35

30.40

12.80

9.80

6.35

81.10

44.20

25.10

41.20

N/A

1.60

N/A

CLQ1TT-3/8"xT1/4"x3/8"

A

24.20

9.80

6.35

6.35

20.20

9.80

6.35

65.50

31.60

19.60

32.75

N/A

1.20

N/A

CLQ1TT-3/8"x1/4"×T3/8"

B

24.20

9.80

6.35

15.72

9.53

6.45

3.95

68.20

32.40

24.10

34.60

N/A

1.60

N/A

CLQ1TT-3/8'xT1/4"xT3/8"

C

24.20

9.80

6.35

6.35

9.53

12.70

N/A

67.80

31.60

24.10

19.10

34.30

1.20

1.60

CLQITT-1/2'xT1/2"x1/4"

A

30.40

12.80

9.53

12.70

15.72

6.35

3.95

83.90

40.70

24.10

39.70

N/A

1.60

N/A

CLQITT-1/2'xT1/2"×T1/2"

c

30.40

12.80

9.53

12.70

12.70

N/A

N/A

83.60

40.10

24.10

24.10

40.10

1.60

1.60

CLQ1TT-1/2"xT1/2"x1/2"

A

30.40

12.80

9.53

12.70

30.40

12.80

9.53

88.00

40.10

24.10

44.20

N/A

1.60

N/A

CLQITT-1/2"×1/2"xT1/2"

B

30.40

12.80

9.53

30.40

12.70

12.80

9.53

83.10

43.50

24.10

40.70

N/A

1.60

N/A

CLQITT-1/2"xT3/4"x1/2"

A

30.40

12.80

9.53

19.00

30.40

12.80

9.53

98.40

50.60

34.60

49.20

N/A

1.60

N/A

CLQ1TT-1/2'xT3/8"x1/2"

A

30.40

12.80

9.53

9.53

30.40

12.80

9.53

81.20

40.60

24.10

40.60

N/A

1.60

N/A

CLQITT-1/2°×3/8"×T1/2"

B

30.40

12.80

9.53

24.20

12.70

9.80

6.35

78.60

39.70

25.10

38.10

N/A

1.60

N/A

CLQITT-T1/2"X1/2"XT1/2"

D

30.40

12.80

9.53

12.70

12.70

N/A

N/A

81.00

44.20

24.40

24.40

N/A

1.60

1.60

CLQ1TT-1/2"x1/4"xT1/2"

B

30.40

12.80

9.53

15.72

6.35

6.45

3.95

83.60

37.10

24.10

40.10

N/A

1.60

N/A

CLQITT-1/2'xT3/4"xT3/4"

C

30.40

12.80

9.53

19.00

19.00

N/A

N/A

104.10

55.60

34.60

34.60

55.60

1.60

1.60

CLQ1TT-3/4"x3/8"×T3/4"

B

42.00

19.20

15.80

24.20

19.00

9.80

6.35

103.00

44.40

35.50

50.50

N/A

1.60

N/A

CLQ1TT-3/4"x1/2"xT3/4"

B

42.00

19.20

15.80

30.40

19.00

12.80

9.53

106.60

48.10

34.60

50.10

N/A

1.60

N/A

CLQ1TT-T3/4"xl/2"xT3/4"

D

30.40

12.80

9.53

19.00

19.00

N/A

N/A

102.20

51.10

34.60

34.60

N/A

1.60

1.60

CLQITT-T3/4"x3/4"xT3/4"

D

42.00

19.20

15.80

19.00

19.00

N/A

N/A

111.20

60.00

34.60

34.60

N/A

1.60

1.60

CLQ1TT-3/4"xT3/4"x1/4"

A

42.00

19.20

15.80

19.00

15.72

6.45

3.95

111.20

55.60

34.60

60.00

N/A

1.60

N/A

CLQ1TT-T3/4"xT3/4"x1/2"

C

30.40

12.80

9.53

19.00

19.00

N/A

N/A

104.10

55.60

34.60

34.60

55.60

1.60

1.60

CLQITT-3/4°xT3/4"×T3/4"

C

42.00

19.20

15.80

19.00

19.00

N/A

N/A

115.60

55.60

34.60

34.60

56.10

1.60

1.60

CLQ1TT-3/4°xT3/4"x3/4"

A

42.00

19.20

15.80

9.53

42.00

19.20

15.80

120.00

60.00

34.60

60.00

N/A

1.60

N/A

CLQ1TT-3/4"x3/4"×T3/4"

B

42.00

19.20

15.80

42.00

19.00

19.20

15.80

115.30

60.00

35.10

55.30

N/A

1.60

N/A

CLQITT-3/4°xT3/4"x1/2"

A

42.00

19.20

15.80

12.80

30.40

12.80

9.53

108.10

55.40

34.60

48.10

N/A

1.60

N/A

CLQITT-3/4×3/4"xTI

B

42.00

19.20

15.80

42.00

25.40

19.20

15.80

125.60

60.00

42.10

65.60

N/A

1.60

N/A

CLQITT-3/4"x3/4"xT1/2"

B

42.00

19.20

15.80

49.20

12.70

19.20

15.80

105.10

60.00

24.10

45.10

N/A

1.60

N/A

CLQ1TT-3/4°xT1/2"xT3/4"

C

42.00

19.20

15.80

12.70

19.00

N/A

N/A

106.60

45.10

34.60

24.10

51.10

1.60

1.60

CLQITT-3/4°xT1/2"x3/4"

A

42.00

19.20

15.80

12.70

42.00

19.20

15.80

111.00

45.10

24.10

55.50

N/A

1.60

N/A

CLQ1TT-3/4°xT3/8"x3/4"

A

42.00

19.20

15.80

9.53

42.00

19.20

15.80

105.00

45.40

24.10

52.50

N/A

1.60

N/A

CLQ1TT-3/4°x1/4"xT3/4"

B

42.00

19.20

15.80

15.72

19.00

6.45

3.95

93.80

40.50

34.60

44,50

N/A

1.60

N/A

CLQ1TT-TI"x1°xT1

D

49.20

25.70

22.20

25.40

25.40

N/A

N/A

141.60

70.50

44.60

45.10

N/A

1.60

1.60

CLQITT-1"x3/8"×T1"

B

49.20

25.70

22.20

24.20

25.40

9.80

22.20

121.30

49.20

44.60

60.50

N/A

1.60

N/A

CLQ1TT-1"xT1"xT1"

C

49.20

25.70

22.20

25.40

25.40

N/A

N/A

140.00

70.80

44.60

44.60

70.80

1.60

1.60

CLQITT-1"xT1'x1"

A

49.20

25.70

22.20

25.40

49.20

25.70

22.20

141.00

70.40

44.60

70.20

N/A

1.60

N/A

CLQ1TT-1"x1"xTI"

B

49.20

25.70

22.20

49.20

25.40

25.70

22.20

141.30

70.80

44.60

70.50

N/A

1.60

N/A

CLQ1TT-1"x3/4"xT1

B

49.20

25.70

22.20

42.00

25.40

19.20

15.80

130.90

65.20

44.60

65.60

N/A

1.60

N/A

CLQITT-1"xTI/2'x1"

A

49.20

25.70

22.20

12.70

49.20

25.70

22.20

121.60

50.40

24.10

50.80

N/A

1.60

N/A

CLQITT-1"x1/2"xT1"

B

49.20

25.70

22.20

30.40

25.40

12.80

9.53

127.40

52.00

44.60

60.50

N/A

1.60

N/A

CLQ1TT-1"×T3/4°x1"

A

49.20

25.70

22.20

19.00

49.20

25.70

22.20

130.60

63.50

44.60

63.50

N/A

1.60

N/A
