Product Description
规格MODEL |
外形尺寸DIMENSIONS(mm) |
||||
D |
d |
d1 |
L |
A |
|
CLQ1H-1/8"-MN |
12.00 |
3.30 |
2.18 |
25.60 |
NPT1/8" |
CLQ1H-1/8"X1/4"-MN |
12.00 |
3.30 |
2.18 |
31.40 |
NPT1/4" |
CLQ1H-1/4"X1/8"-MN |
16.90 |
6.45 |
3.95 |
34.00 |
NPT1/8" |
CLQ1H-1/4"-MN |
16.90 |
6.45 |
3.95 |
37.00 |
NPT1/4" |
CLQ1H-1/4"X3/8"-MN |
16.90 |
6.45 |
3.95 |
39.50 |
NPT3/8" |
CLQ1H-1/4"X1/2"-MN |
16.90 |
6.45 |
3.95 |
42.40 |
NPT1/2" |
CLQ1H-3/8"X1/4"-MN |
24.20 |
9.80 |
6.35 |
42.90 |
NPT1/4" |
CLQ1H-3/8"-MN |
24.20 |
9.80 |
6.35 |
43.90 |
NPT3/8" |
CLQ1H-3/8"X1/2"-MN |
24.20 |
9.80 |
6.35 |
46.90 |
NPT1/2" |
CLQ1H-1/2"X1/4"-MN |
30.40 |
12.80 |
953 |
47.50 |
NPT1/4" |
CLQ1H-1/2"X3/8"-MN |
30.40 |
12.80 |
9.53 |
47.30 |
NPT3/8" |
CLQ1H-1/2"-MN |
30.40 |
12.80 |
9.53 |
52.00 |
NPT1/2" |
CLQ1H-1/2"X3/4"-MN |
30.40 |
12.80 |
9.53 |
50.50 |
NPT3/4" |
CLQ1H-3/4"X1/2"-MN |
42.00 |
19.20 |
15.80 |
64.60 |
NPT1/2" |
CLQ1H-3/4"-MN |
42.00 |
19.20 |
15.80 |
63.50 |
NPT3/4" |
CLQ1H-3/4"X1"-MN |
42.00 |
19.20 |
15.80 |
65.80 |
NPT1" |
CLQ1H-1"X3/4"-MN |
49.20 |
25.70 |
22.20 |
70.30 |
NPT3/4" |
CLQ1H-1"-MN |
49.20 |
25.70 |
22.20 |
71.10 |
NPT1" |
CLQ1H-1/8"-MR |
12.00 |
3.30 |
2.18 |
25.60 |
R1/8" |
CLQ1H-1/8"X1/4"-MR |
12.00 |
3.30 |
2.18 |
31.40 |
R1/4" |
CLQ1H-1/4"X1/8"-MR |
16.90 |
6.45 |
3.95 |
34.00 |
R1/8" |
CLQ1H-1/4"-MR |
16.90 |
6.45 |
3.95 |
37.00 |
R1/4" |
CLQ1H-1/4"X3/8"-MR |
16.90 |
6.45 |
395 |
39.50 |
R3/8" |
CLQ1H-1/4"X1/2"-MR |
16.90 |
6.45 |
3.95 |
42.40 |
R1/2" |
CLQ1H-3/8"X1/4"-MR |
24.20 |
9.80 |
6.35 |
42.90 |
R1/4" |
CLQ1H-3/8"-MR |
24.20 |
980 |
6.35 |
43.90 |
R3/8" |
CLQ1H-3/8"X1/2"-MR |
24.20 |
9.80 |
635 |
46.90 |
R1/2" |
CLQ1H-1/2"X1/4"-MR |
30.40 |
12.80 |
9.53 |
47.50 |
R1/4" |
CLQ1H-1/2"X3/8"-MR |
30.40 |
12.80 |
9.53 |
47.30 |
R3/8" |
CLQ1H-1/2"-MR |
30.40 |
12.80 |
9.53 |
52.00 |
R1/2" |
CLQ1H-1/2"X3/4"-MR |
30.40 |
12.80 |
9.53 |
50.80 |
R3/4" |
CLQ1H-3/4"X1/2"-MR |
42.00 |
19.20 |
15.80 |
64.60 |
R1/2" |
CLQ1H-3/4"-MR |
42.00 |
19.20 |
15.80 |
63.50 |
R3/4" |
CLQ1H-3/4"X1"-MR |
42.00 |
19.20 |
15.80 |
65.80 |
R1 |
CLQ1H-1"X3/4°-MR |
49.20 |
25.70 |
22.20 |
70.30 |
R3/4" |
CLQ1H-1"-MR |
49.20 |
25.70 |
22.20 |
71.10 |
R1" |
规格MODEL |
外形尺寸DIMENSIONS (mm) |
||||
D |
d |
d1 |
L |
A |
|
CLQ1H-4X1/8"-MN |
12.00 |
4.00 |
3.00 |
26.00 |
NPT1/8" |
CLQ1H-4X1/4"-MN |
12.00 |
4.00 |
3.00 |
28.90 |
NPT1/4" |
CLQ1H-6X1/8"-MN |
16.90 |
6.10 |
4.00 |
34.20 |
NPT1/8" |
CLQ1H-6X1/4°-MN |
16.90 |
6.10 |
4.00 |
37.40 |
NPT1/4" |
CLQ1H-6X3/8"-MN |
16.90 |
6.10 |
4.00 |
39.90 |
NPT3/8" |
CLQ1H-6X1/2"-MN |
16.90 |
6.10 |
4.00 |
42.10 |
NPT1/2" |
CLQ1H-8X1/2"-MN |
24.70 |
8.10 |
6.00 |
46.20 |
NPT1/2" |
CLQ1H-12X1/2"-MN |
30.40 |
12.00 |
10.00 |
50.30 |
NPT1/2" |
CLQ1H-4X1/8"-MR |
12.00 |
4.00 |
3.00 |
26.00 |
R1/8" |
CLQ1H-4X1/4°-MR |
12.00 |
4.00 |
3.00 |
28.90 |
R1/4" |
CLQ1H-6X1/8"-MR |
16.90 |
6.10 |
4.00 |
34.20 |
R1/8" |
CLQ1H-6X1/4"-MR |
16.90 |
6.10 |
4.00 |
37.40 |
R1/4" |
CLQ1H-6X3/8"-MR |
16.90 |
6.10 |
4.00 |
39.90 |
R3/8" |
CLQ1H-6X1/2"-MR |
16.90 |
6.10 |
4.00 |
42.10 |
R1/2" |
CLQ1H-8X1/2"-MR |
24.70 |
8.10 |
6.00 |
46.20 |
R1/2" |
CLQ1H-12X1/2"-MR |
30.40 |
12.00 |
10.00 |
50.30 |
R1/2" |
